DRYWALL STUDS & STEEL JOISTS FOR STEEL FRAMING CONSTRUCTION
Woodland Building Supply is a proud supplier of OEG Metal Framing and Decking Building Materials.
We stock 20 and 25 gauge metal studs and track: 1 5/8″, 2 1/2″, 3 5/8″, and 6″.
Other sizes and gauges are available by special order. Scroll down to view all of the metal framing and decking materials that we carry.
INTERIOR FRAMING
Phantom
Phantom® Stud is the steel drywall stud for interior cold formed framing. Its design combines high-strength steel with additional stiffening enhancements for a drywall-framing stud.
Deep Leg Track
OEG Deep Leg Track also known as Deflection Track is used to accommodate the building deflection at the head of the wall.
Slotted Track
OEG Slotted Track is used to accommodate building deflection at the head of wall.
CT Shaftwall
OEG CT Shaftwall Stud is a rigid member engineered to maintain shaftwall integrity and are used with 1″ thick gypsum shaft-liner panels. Gypsum shaft-liners can be easily aligned in the flanges of the CT Stud.
STRUCTURAL FRAMING
Big Apple Joist
OEG Big Apple Joist® is a revolutionary floor joist system that is engineered and designed to provide fast installation of floors thus reducing the overall construction time-frame and cost.
Big Apple K-Joist
Big Apple K-Joist® is an I-shaped component that is stronger than conventional C-shaped joists.
Structural Stud
OEG Structural Studs are general purpose framing component used in a variety of applications including load bearing interior and exterior walls, non-load bearing exterior curtain-walls, floor joists and headers, roof trusses, rafters and purlins.
Structural Track
Structural Tracks are U-shaped channels used as the top and bottom tracks to secure wall studs or end support closures for floor joist framing.
DECKING
Floor (Composite)
Steel floor decks, engineered for use in composite slab design, furnish positive reinforcement for the concrete slab and can eliminate the need for any additional positive reinforcing.
Roof
Roof decks are made of cold formed steel sheets and supported in applications by steel joists or beams.
Form
Form Deck is a term used to describe deck that is most frequently used as a stay in place form for structural concrete.
ACCESSORIES
J-Tabbed Track
OEG J-Tabbed Track are used in conjunction with OEG CT Shaftwall Studs, which are friction fitted at top and bottom of CT Studs.
J-Track
OEG J-Track is an uneven legged J-shaped track primarily installed with shaftwall systems for an economical and durable solution.
Corner Bead
OEG Corner Bead is used in drywall corners and provides a high quality finish and protection to edges.
Dull Corner Bead
Dull Corner Bead has perforated and knurled flanges which provide excellent adhesion.
Paper-Faced Corner Bead
OEG Paper-Faced Corner Bead virtually eliminates the corner cracks in wall edges.
Corner Angle
OEG Corner Angle is a non-structural utility angle used to enclose, connect, and secure various applications in drywall and stud framing.
Resilient Channel (RC-1)
OEG Resilient Channel (RC-1) is a single leg channel that is the most efficient and low cost solution to reduce the transmission of noise in partition walls.
Resilient Channel (RC-2)
OEG Resilient Channel (RC-2) is a double legged channel that is the most efficient and low cost solution to reduce the transmission of noise in partition walls and ceiling assemblies.
J-Trim
OEG J-Trim is a corrosion-resistant component used near corners of drywall systems and edges of door and window openings.
Joist Blocking
Joist blocking is pre-cut to fit securely between floor joists to prevent joist rotation against lateral torsional buckling.
Joist Hanger
OEG Top Flange Joist Hanger is used to connect joists with cold formed steel headers and structural steel beams.
Square Joist Hanger
OEG Square Joist Hanger is used to connect joists with cold formed steel headers and structural steel beams.
Hat Channel
OEG furring channel is a hat-shaped corrosion-resistant multi-purpose component used to support roof framing and ceiling assemblies, gypsum board, veneers to the exterior concrete wall and more.
Z-Furring
OEG Z Furring Channel is a Z-shaped corrosion-resistant multi-purpose component used to support rigid insulation in gypsum wallboards, interior masonry walls and more.
U Channel
OEG U-Channel is a general purpose framing component commonly used where bridging is required.
Web Stiffener
OEG Web Stiffener is a structural component, used to provide reinforcement in the web of joists to resist web crippling at critical load points.
Flat Stock
OEG Blocking/Strapping is commonly used as bracing for studs with depths greater than 6″.
Deflection Clip
OEG Deflection Clip is a structural component used in the deflection of exterior curtain walls to main structure.
Stif Clip
OEG Stif Clip secures the cold-rolled channel to wall studs 3-5/8″ through 8″.
